Kubota R430

Kubota R430 Wheel Loader

Compact design with impressive power allows the R430 to get the work done where larger loaders can't fit. The R430 also delivers big on comfort in every season with an available enclosed cab featuring heat and A/C.

Features

POWERFUL KUBOTA ENGINE

The R430 boasts a gross rating of 47.6 HP (SAE J 1995) that provides the extra muscle needed for all of the chores that the loader is capable of performing.

COMFORTABLE WORK STATION

Comfort and convenience are the keys to operator efficiency. The working station is mounted on rubber ISO mounts to minimize sounds and vibrations. Increase your comfort level in all seasons with an enclosed heated and A/C cooled cab.

LOAD SENSING TRANSMISSION

As the travel and loading conditions change, the R430's transmission automatically shifts to compensate to provide maximum torque and speed for efficient ground speed operation. The manual switch can be operated with a convenient button located on the loader control level.

LIMITED SLIP DIFFERENTIAL

Mud, sand, snow are no problem for the R430's front limited slip axle. If a front wheel slips, the power is transferred to the opposite wheel to restore traction.

REAR BACKHOE

The R430 takes versatility to a new level in compact wheel loaders with an optional backhoe attachment. The RBK4009SA backhoe allows the operator to dig a trench up to seven feet deep and 24 inches wide.

HYBRID LINK DESIGN

The well-balanced cylinder position of the Z link provides strong bucket break out forces and a lift path almost parallel to the ground for superior reach and lift.

Specs

Engine

Engine D1803-CR-TIE4-WL5 Emissions Tier 4 Output (SAE J1995 gross) HP (kW)/rpm 47.6 (35.5) / 2600 Output (SAE J1349 net) HP (kW)/rpm 44.5 (33.2) / 2600 Displacement cu.in. (cc) 111 (1826)

Transmission

Type Hydrostatic Transmission

Dimensions

Overall Length (mm) 14' 4" (4355) Overall Height 8' 3" (2515) Overall Width (w/o Bucket) 4' 12" (1520) Ground Clearance 11"

Auxiliary Circuit

Auxiliary Hydraulic Flow 11.1 (42.1) Auxiliary Hydraulic Pressure 2697 (18.6)

Drive System

Tire Size 12.5 / 70-16-8PR Travel Speed Low/High 3 mph / 12.4 mph Max. Traction Force 5485 lbs Front Axle Traction Lock Limited Slip Differential Articulation Angle 40° (Each Direction) Angle of Rear Frame Oscillation ±8° Loader Clearance Circle 12' 1" (3695) Turning Radius Track Circle 10' 1" (3085) Brakes (Service) Enclosed Wet Disc Brakes (Parking) Spring Applied Hydraulic Released Wet Disc

Lifting Specifications

Tipping Load (Straight (w/ Bucket)) 5335 (5743) lbs Tipping Load (Straight (w/ Pallet Forks)) 5743 (3770) lbs Tipping Load (Full Turn (w/ Bucket)) 4596 (4949) lbs Tipping Load (Full Turn (w/ Pallet Forks)) 3009 (3251) lbs Rated Operating Capacity (50% of Tipping Load (w/ Bucket)) 2298 (2474) lbs Rated Operating Capacity (50% of Tipping Load (w/ Pallet Forks)) 1504 (1625) lbs

Operational Specifications

Standard Bucket Capacity .5 yd³ Breakout Force 5215 lbs Lifting Capacity at Ground Level 3687 lbs Loader Raise / Lower Time 4.4 / 3.3 sec Fuel Tank 14.3 gal Hydraulic System 15.3 gal Hydraulic Reservoir 11.1 gal Operating Weight (Including Operator Weight @ 165 lbs) 7758 (8232)
